Features:
This machine is produced and designed based on 4ft wood log debarking machine, applicable for 1000-2600mm wood log debarking work. Due to 8ft wood log debarker long working width, our company added two strong rail guiding device in this debarking lathe, and we have special and conderable design in the debarking cutting table track slot, ensure this machine working stably, extending working life, convenient to do maintenance. Machines can be customized according to customer's requirements.
Technical parameters:
| Model No. | YDB/8 |
| Wood length | 1000-2600mm |
| Wood diameter | Φ80-Φ500mm |
| Blade length | 1900mm |
| Thickness of veneer peeler | 1-3mm |
| Linear speed of host machine | 52mm/min |
| Double roller diameter | 200mm |
| Single roller diameter | 150mm |
| Double roller motor power | 7.5kw*2pcs |
| Single roller motor power | 7.5kw*2pcs |
| Hydraulic station motor power | 5.5kw |
| Total power | 35.5kw |
| Total weight | 4800kg |
| Machine dimension | 5000*2300*1600mm |
