1. Nanjing servo control system, 6 sensor switches, with memory function (remember the position of saw edge plate), can accurately locate the position of the plate. With servo motor traction, two - axis linkage, fast speed, large output, arbitrary programming, two - person operation, greatly reduced labor costs.
2. The size of the sawing side can be adjusted at any size 36-48.
3. Base is welded.Let machine runs smoothly and with high accuracy.circulating lubricating oil have long service life.
4. 6 saw blades (4 big 2 small), speed up to 6800 rpm, underlined function, fully solve the rendering, burr, burr, core pulling phenomenon, sawing smooth, without polishing.
5. Infrared positioning, automatic platoon, load track saw edge, four cylinder positioning, high edge straightness, no corner phenomenon.
6. Automatic lifting platform, automatic stacking. The installation of lifting platen limiting device has completely solved the problem of uneven packing.
7. The automatic saw machine has the effect of dust removal from top to bottom.
| Model No. | JS36-48-1-N |
| Processing length & width | 1220mm *2440mm |
| Processing thickness | 3-60mm |
| Loading speed | 0 -30m/min |
| Sawing blade diameter | 305mm |
| Sawing blade working speed | 6200rpm/min |
| First saw motor power | 15kw |
| Second saw motor power | 15kw |
| Servo motor power | 4.8kw |
| Bottom line saw cutting motor power | 2.2kw |
| Board lifter motor power | 3kw |
| Total power | 40kw |
| Total weight | 5500kg |
| Machine overall dimension | 7000*5000*1800mm |
